Update Onagofly Firmware on Mac OS X

by · Published · Updated

It is possible to update the firmware on an Onagofly micro drone on Mac OS X using the QGroundControl software. The download for the software can be found here: http://qgroundcontrol.org/downloads.

You will also need the firmware provided by Onagofly, which is currently version 630. The firmware (with modified file extension) can be found here: https://www.dropbox.com/s/7kwutj5dnbycr0k/ONAGOfly0630.px4?dl=1

Step 1: Change firmware extension to px4

This step is not necessary if you downloaded the firmware using the link in this post, but by default the firmware file is named ONAGOfly0630.ong. This means you will need to rename it to ONAGOfly0630.px4 as the QGroundControl app will only allow you to select *.hex, *.bin, and *.px4 files, and since we are uploading firmware to the Pixhawk PX4 FMU…

Step 2: Prepare Drone

Leave the drone powered off, or disconnect the battery entirely if you are able, and connect a micro USB cable.

Step 3: Open QGroundControl

Without connecting it to your computer, start up QGroundControl.

QGroundControl-OnagoFly-1



Step 4: Select “Firmware”

This is mode allows QGroundControl to update the firmware on the Onagofly. Plug in (or unplug and re-plug in) the USB cable to detect the Pixhawk flight controller.

QGroundControl-OnagoFly-2

Step 5: Configure firmware update

Once your device is detected, you will need to change the firmware settings to properly update using the Onagofly firmware, rather than the default PX4 or ArduPilot stack.

  1. Select “ArduPilot Flight Stack”
    1. Quad – APM:Copter V3.3.3
  2. Check the “Advanced settings” box
    1. Choose “Custom firmware file…”
  3. Click OK.

QGroundControl-OnagoFly-3

Step 6: Select firmware file

Navigate to the location of the ONAGOfly0630.px4 firmware file and select it.

QGroundControl-OnagoFly-4

Step 7: Update Complete

You should see some status updates followed by a message saying “Upgrade complete”. A few seconds later you should hear the startup noise, and the device will be detected by QGroundControl.

QGroundControl-OnagoFly-5



It took several attempts to get the firmware to properly upload, so if it is unsuccessful, try again. When I was finally able to load the firmware, I first loaded the Beta ArduCopter stack, then the Onagofly. Good luck!

Tags:

You may also like...

30 Responses

  1. Iain Hamilton says:
    October 5, 2017 at 2:47 am

    Hi Justin, i have just done this upgrade and something strange is happening. When i plug the charger in, the lights on the charger now have a fast flicker rather than a one, two, there, four pattern that was occurring directly before the update. I’m waiting to see what will happen. Also, the copter3.3.3 wasn’t listed, only copter 3.5.3, so i used that, is this the problem?

    Thanks

    Iain.

    Reply
    • Justin Silver says:
      October 10, 2017 at 11:54 am

      To be honest I’m not really sure. I ended up giving up on the Onago after never really getting it to work. Getting a Mavic Pro was the right call for me – more money but a lot less of a hassle for MUCH better results. Sorry I can’t be of more help – good luck!

      Reply
      • Iain Hamilton says:
        October 12, 2017 at 9:13 am

        Hi thanks for the reply, do you know if there at least a way to simply put the original FW back on, it doesn’t work at all now 🙁

        Reply
        • Justin Silver says:
          October 13, 2017 at 11:57 am

          Unfortunately I’m not sure where to get the original firmware file – I got the newer one from a forum or some such thing. It did take me several attempts to get the firmware to load and work, so you might want to try it again. I also tried loading an Arducopter firmware first and then the one linked to here so maybe that’s something else to try. I wish I could help more but I never made it that far with the Onago myself.

          Reply
  2. jc says:
    September 4, 2016 at 10:03 am

    hi justin
    my onago have a pb with wifi..
    any idea to reset everything. the wifi not working at all now?

    Reply
  3. Steve Lane says:
    August 1, 2016 at 6:27 pm

    I use my fingernails to lift the black GPS cover. A guitar pic or the tools used for opening iPods etc will work just fine. I put a stick on paper dot on the cover and the O body so that it will go back the right way round or the antenna won’t reconnect. You will see the antenna appears to be just a 6.5mm square tab.I have looked at GPS antenna on all kinds of mobiles and they come in a wide variety of shapes and sizes. The one I am going to try looks like just a 60m length of wire. Unfortunately, I live in a basement apartment with zero GPS so I have to go outside to get reception. I will let you know how I get on. I think a degree in either Magic or antenna design would be good. As I have neither I will try the guestimation method.

    Reply
  4. Steve Lane says:
    August 1, 2016 at 1:44 pm

    Hi Justin. Do you know of any way to improve GPS reception? I have flipped the lid to examine the antenna and it looks to be too small to be effective. I am going to experiment with one intended for a Sony Xperia Z3. that one looks like a full wave antenna. I was wondering if you had experimented?

    Reply
    • Justin Silver says:
      August 1, 2016 at 1:48 pm

      I also considered replacing the GPS antenna, but I haven’t done any experimenting yet. I actually haven’t even opened it up yet because I keep forgetting to buy a screwdriver with a narrow shaft, but I can tell that it’s a Pixhawk PX4FMU, so it’s possible that the entire GPS module could be upgraded: https://pixhawk.org/peripherals/sensors/gps. Keep me posted!

      Reply
  5. jc says:
    July 30, 2016 at 1:25 am

    hello
    after i install the firmware, do i have to set the drone with QGroundControl ?

    please advise

    Reply
    • Justin Silver says:
      August 1, 2016 at 10:25 am

      Hi JC – I only used QGroundControl to install the firmware. You might be able to do some other things with it as well since it is compatible with the FMU in the Onagofly, but I haven’t done any experimenting with it.

      Reply
  6. Yu-Li says:
    July 26, 2016 at 6:54 pm

    Hi, Justin. I connected my OnagoFly after I started the qgroundcontrol. The OnagoFly started blinking sort of purple light and then it turned to steady orange light. But qgroundcontrol somehow was not able to detect the O. I tried unplug and plug back, the result was the same. What else should I do? Thank you very much.

    Reply
    • Justin Silver says:
      July 27, 2016 at 7:48 pm

      If you select the firmware upgrade and remove and re-insert the USB cable is it able to detect the quad?

      Reply
  7. Chris says:
    July 26, 2016 at 5:34 am

    Hi Justin. I have forgotten my password ( for the wifi) connection with the OnagoFly! I tried the firmware update, but it leaves the password in tact. Unfortunately i no longer can connect with my onagofly, any idea how this can be solved? You seem to be an expert in this field?
    Appreciate your ideas’ thanks chris

    Reply
  8. Phil says:
    July 19, 2016 at 5:02 pm

    SOOO, back to iMac and using the media fire download got the file and managed to complete the firmware upgrade. Unable to check what version was on it originally and currently.
    Still no love with the unlock feature to start props in IOS app. Stumped for ideas. No one i know has an Android phone to test and see if it’s an IOS app issue or com issue to drone or firmware issue?

    Thanks for your help today!

    Phil

    Reply
    • Blas Cabrera says:
      July 22, 2016 at 8:36 pm

      I found the same unlock problem with my black version. I solved it going into settings and turning on locations services for onagofly app when app is open.

      Reply
  9. Phil says:
    July 19, 2016 at 1:40 am

    Just got my black version today. Figured the memory card issue with wifi and gps easy enough. Can’t get to responses to the unlock command in iOS app?
    Did firmware improve performance??

    Reply
    • Justin Silver says:
      July 19, 2016 at 10:14 am

      I wasn’t able to unlock the props when I had the standard Arducopter firmware installed, but it did work once I used the custom firmware file from Onagofly. The update did improve performance, however it can still be very erratic at time. The good news is that it seems like the problem is with the software and not the hardware, so there is still hope…

      Reply
      • Phil says:
        July 19, 2016 at 12:43 pm

        The Dropbox link above only provides me with a text file. How do i convert this to a useable firmware?
        Thanks in advance.

        Reply
        • Justin Silver says:
          July 19, 2016 at 12:57 pm

          Interesting – I hadn’t opened the file in a text editor before. It looks like the ONAGOfly630.px4 (the renamed ONAGOfly630.ong) is a JSON file and looks contains the following:

          {
    "board_id": 9,
    "magic": "PX4FWv1",
    "description": "Firmware for the PX4FMUv2 board",
    "image":"... long encoded text string ...",
    "build_time": 1464334813,
    "summary": "PX4FMUv2",
    "version": "0.1",
    "image_size": 765072,
    "git_identity": "",
    "board_revision": 0
}

          The image property is where it gets the data to write to the flash I imagine, you just need to save the text file to your computer, then select it when choosing custom firmware in QGroundControl.

          Reply
          • Phil says:
            July 19, 2016 at 1:26 pm

            When i click the link it downloads file called ONAGOfly0630.px4-2.txt and nothing else. Renaming won’t work because the file ends with .txt. Do i need to convert the text file to JSON file?
            Did you download a .ong file?
            Maybe something has changed in the drop box?

            Reply
            • Phil says:
              July 19, 2016 at 3:01 pm

              So I get a lot further with my net book and windows BUT fail at the last hurdle. The flash halts with the following message.

              QGroundControl can upgrade the firmware on Pixhawk devices, SiK Radios and PX4 Flow Smart Cameras.
All QGroundControl connections to vehicles must be disconnected prior to firmware upgrade.
Please unplug your Pixhawk and/or Radio from USB.
Plug in your device via USB to start firmware upgrade.
Found device: Pixhawk
Connected to bootloader:
Version: 4
Board ID: 9
Flash size: 2080768
Downloading firmware...
From: C:/Users/Reester78/Downloads/ONAGOfly0630.px4
Download complete
MAV_AUTOPILOT = 12
Firmware file missing parameter_xml_size key
Firmware file missing airframe_xml_size key
Succesfully decompressed image
Erasing previous program...
Erase complete
Programming new version...
Error: Flash failed: Write failed: OS error: The semaphore timeout period has expired. at address 0x00088240
Upgrade cancelled
------------------------------------------
If upgrade failed, make sure to connect directly to a powered USB port on your computer, not through a USB hub. Also make sure you are only powered via USB not battery.
              Reply
              • Justin Silver says:
                July 19, 2016 at 3:07 pm

                Hard to say what the issue is, something isn’t allowing it to write to the flash drive. You could try a different USB cable, make sure that the battery is unplugged on the drone… otherwise, maybe give Mission Planner or APM Planner a try? I used QGroundControl on my Mac, not Windows so not sure if there are some caveats there. Did you install the Windows px4 drivers? https://pixhawk.org/firmware/downloads

                Reply
            • Justin Silver says:
              July 19, 2016 at 3:05 pm

              Not sure why it would be renaming the file, it should just be ONAGOfly0630.px4. I assume the content is there, so you just need to rename it to *.px4, but if not Onago posted this as well – you just need to rename the *.ong to *.px4: https://www.mediafire.com/folder/9li3j68v9qc58/How_to_update_Firmware_of_ONAGOfly

              Reply
    • Blas Cabrera says:
      July 22, 2016 at 12:56 pm

      I found the same problem with my black version. I solved it going into settings and turning on locations services for onagofly app when app is open.

      Reply
  10. Blas Cabrera says:
    July 17, 2016 at 11:43 am

    How do you determine whether firmware needs to be updated?
    Which version of iOS app is needed for this firmware update?
    Will you post each time there is a new firmware update?

    Reply
    • Justin Silver says:
      July 17, 2016 at 12:07 pm

      The only way I was able to view the firmware version was by using APM Planner under Flight Data > Info View > Messages. This is what it shows for me after the firmware upgrade:

      [MAV 001:1] ArduCopter V3.2.1 zddll (HEAD)
[MAV 001:1] PX4: HEAD NuttX: HEAD
[MAV 001:1] Frame: QUAD
[MAV 001:1] PX4v2 00290041 3335510C 37343436

      I can’t guarantee that I will post every update, but I can try 🙂

      Reply
      • Blas Cabrera says:
        July 23, 2016 at 7:19 am

        I am unable to get APM Planner to work for me. However, I was able to find the post date for the firmware by entering https://www.dropbox.com/s/7kwutj5dnbycr0k/ONAGOfly0630.px4 which gives the DropBox window saying that the firmware was posted on May 27, 2016. Since I received my black drone on July 1, 2016, I am assuming that it does have the most recent firmware version. That date also means that the 0630 number in the file name is not the post date.

        Reply
